| enum | Rate {
rateUnknown,
rate6khz = 6000,
rate8khz = 8000,
rate16khz = 16000,
rate32khz = 32000,
rate44khz = 44100
} |
| | Audio encoding rate, samples per second. More...
|
| |
| typedef enum Rate | Rate |
| |
| enum | Mode {
modeRead,
modeReadAny,
modeReadOne,
modeWrite,
modeCache,
modeInfo,
modeFeed,
modeAppend,
modeCreate
} |
| | File processing mode, whether to skip missing files, etc. More...
|
| |
| typedef enum Mode | Mode |
| |
| enum | Encoding {
unknownEncoding = 0,
g721ADPCM,
g722Audio,
g722_7bit,
g722_6bit,
g723_2bit,
g723_3bit,
g723_5bit,
gsmVoice,
msgsmVoice,
mulawAudio,
alawAudio,
mp1Audio,
mp2Audio,
mp3Audio,
okiADPCM,
voxADPCM,
sx73Voice,
sx96Voice,
cdaStereo,
cdaMono,
pcm8Stereo,
pcm8Mono,
pcm16Stereo,
pcm16Mono,
pcm32Stereo,
pcm32Mono,
speexVoice,
speexAudio,
g729Audio,
ilbcAudio,
speexUltra,
speexNarrow = speexVoice,
speexWide = speexAudio,
g723_4bit = g721ADPCM
} |
| | Audio encoding formats. More...
|
| |
| typedef enum Encoding | Encoding |
| |
| enum | Format {
raw,
snd,
riff,
mpeg,
wave
} |
| | Audio container file format. More...
|
| |
| typedef enum Format | Format |
| |
| enum | DeviceMode { PLAY,
RECORD,
PLAYREC
} |
| | Audio device access mode. More...
|
| |
| typedef enum DeviceMode | DeviceMode |
| |
| enum | Error {
errSuccess = 0,
errReadLast,
errNotOpened,
errEndOfFile,
errStartOfFile,
errRateInvalid,
errEncodingInvalid,
errReadInterrupt,
errWriteInterrupt,
errReadFailure,
errWriteFailure,
errReadIncomplete,
errWriteIncomplete,
errRequestInvalid,
errTOCFailed,
errStatFailed,
errInvalidTrack,
errPlaybackFailed,
errNotPlaying,
errNoCodec
} |
| | Audio error conditions. More...
|
| |
| typedef enum Error | Error |
| |
| typedef int16_t | snd16_t |
| |
| typedef int32_t | snd32_t |
| |
| typedef int16_t | Level |
| |
| typedef int16_t | Sample |
| |
| typedef int16_t * | Linear |
| |
| typedef unsigned long | timeout_t |
| |
| typedef unsigned char * | Encoded |
| |
|
| virtual | ~AudioDevice () |
| |
| virtual unsigned | putSamples (Linear buffer, unsigned count)=0 |
| | Copy linear samples to an audio device through its virtual. More...
|
| |
| virtual unsigned | getSamples (Linear buffer, unsigned count)=0 |
| | Copy linear samples from an audio device through its virtual. More...
|
| |
| virtual ssize_t | putBuffer (Encoded data, size_t count) |
| | Copy audio encoded in the currently selected encoding for the audio device. More...
|
| |
| virtual ssize_t | getBuffer (Encoded data, size_t count) |
| | Record audio encoded in the currently selected encoding for the audio device. More...
|
| |
| virtual bool | setEncoded (Info &info) |
| | Use encoding source descriptor to select the audio encoding format the audio device should be using. More...
|
| |
| virtual bool | setAudio (Rate rate=rate8khz, bool stereo=false, timeout_t framing=20)=0 |
| | Set properties for audio device. More...
|
| |
| virtual void | sync (void) |
| | Synchronize timing for audio device to next audio frame. More...
|
| |
| virtual void | flush (void)=0 |
| | Flush any pending buffered samples in audio device. More...
|
| |
| unsigned | bufMono (Linear buffer, unsigned count) |
| | Process linear mono audio and automatically convert to the encoding format the audio device is currently using. More...
|
| |
| unsigned | bufStereo (Linear buffer, unsigned count) |
| | Process linear stereo audio and automatically convert to the encoding format the audio device is currently using. More...
|
| |
| Info * | getInfo (void) |
| | Get audio device source descriptor in effect for the device. More...
|
| |
| bool | isEnabled (void) |
| | Whether device is currently enabled. More...
|
| |
| Encoding | getEncoding (void) |
| | Generic get encoding. More...
|
| |
| unsigned | getSampleRate (void) |
| | Generic sample rate. More...
|
| |
| ssize_t | putNative (Encoded data, size_t size) |
| | Puts raw data and does native to refined endian swapping if needed based on encoding type and local machine endian. More...
|
| |
| ssize_t | getPacket (Encoded data) |
| | Get's a packet of audio data. More...
|
| |
| ssize_t | getNative (Encoded data, size_t size) |
| | Get raw data and assure is in native machine endian. More...
|
| |
|
| static Encoding | getEncoding (const char *name) |
| | Get the audio encoding format that is specified by a short ascii name. More...
|
| |
| static Level | tolevel (float dbm) |
| | Convert dbm power level to integer value (0-32768). More...
|
| |
| static float | todbm (Level power) |
| | Convert integer power levels to dbm. More...
|
| |
| static bool | hasDevice (unsigned device=0) |
| | Test for the presense of a specified (indexed) audio device. More...
|
| |
| static AudioDevice * | getDevice (unsigned device=0, DeviceMode mode=PLAY) |
| | Get a audio device object that can be used to play or record audio. More...
|
| |
| static const char * | getCodecPath (void) |
| | Get pathname to where loadable codec modules are stored. More...
|
| |
| static const char * | getMIME (Info &info) |
| | Get the mime descriptive type for a given Audio encoding description, usually retrieved from a newly opened audio file. More...
|
| |
| static const char * | getName (Encoding encoding) |
| | Get the short ascii description used for the given audio encoding type. More...
|
| |
| static const char * | getExtension (Encoding encoding) |
| | Get the preferred file extension name to use for a given audio encoding type. More...
|
| |
| static Encoding | getStereo (Encoding encoding) |
| | Get the stereo encoding format associated with the given format. More...
|
| |
| static Encoding | getMono (Encoding encoding) |
| | Get the mono encoding format associated with the given format. More...
|
| |
| static bool | isLinear (Encoding encoding) |
| | Test if the audio encoding format is a linear one. More...
|
| |
| static bool | isBuffered (Encoding encoding) |
| | Test if the audio encoding format must be packetized (that is, has irregular sized frames) and must be processed only through buffered codecs. More...
|
| |
| static bool | isMono (Encoding encoding) |
| | Test if the audio encoding format is a mono format. More...
|
| |
| static bool | isStereo (Encoding encoding) |
| | Test if the audio encoding format is a stereo format. More...
|
| |
| static Rate | getRate (Encoding encoding) |
| | Return default sample rate associated with the specified audio encoding format. More...
|
| |
| static Rate | getRate (Encoding e, Rate request) |
| | Return optional rate setting effect. More...
|
| |
| static timeout_t | getFraming (Encoding encoding, timeout_t timeout=0) |
| | Return frame timing for an audio encoding format. More...
|
| |
| static timeout_t | getFraming (Info &info, timeout_t timeout=0) |
| | Return frame time for an audio source description. More...
|
| |
| static bool | isEndian (Encoding encoding) |
| | Test if the endian byte order of the encoding format is different from the machine's native byte order. More...
|
| |
| static bool | isEndian (Info &info) |
| | Test if the endian byte order of the audio source description is different from the machine's native byte order. More...
|
| |
| static bool | swapEndian (Encoding encoding, void *buffer, unsigned number) |
| | Optionally swap endian of audio data if the encoding format endian byte order is different from the machine's native endian. More...
|
| |
| static bool | swapEndian (Info &info, void *buffer, unsigned number) |
| | Optionally swap endian of audio data if the audio source description byte order is different from the machine's native endian byte order. More...
|
| |
| static void | swapEncoded (Info &info, Encoded data, size_t bytes) |
| | Optionally swap endian of encoded audio data based on the audio encoding type, and relationship to native byte order. More...
|
| |
| static Level | getImpulse (Encoding encoding, void *buffer, unsigned number) |
| | Get the energey impulse level of a frame of audio data. More...
|
| |
| static Level | getImpulse (Info &info, void *buffer, unsigned number=0) |
| | Get the energey impulse level of a frame of audio data. More...
|
| |
| static Level | getPeak (Encoding encoding, void *buffer, unsigned number) |
| | Get the peak (highest energy) level found in a frame of audio data. More...
|
| |
| static Level | getPeak (Info &info, void *buffer, unsigned number=0) |
| | Get the peak (highest energy) level found in a frame of audio data. More...
|
| |
| static void | toTimestamp (timeout_t duration, char *address, size_t size) |
| | Provide ascii timestamp representation of a timeout value. More...
|
| |
| static timeout_t | toTimeout (const char *timestamp) |
| | Convert ascii timestamp representation to a timeout number. More...
|
| |
| static int | getFrame (Encoding encoding, int samples=0) |
| | Returns the number of bytes in a sample frame for the given encoding type, rounded up to the nearest integer. More...
|
| |
| static int | getCount (Encoding encoding) |
| | Returns the number of samples in all channels for a frame in the given encoding. More...
|
| |
| static unsigned long | toSamples (Encoding encoding, size_t bytes) |
| | Compute byte counts of audio data into number of samples based on the audio encoding format used. More...
|
| |
| static unsigned long | toSamples (Info &info, size_t bytes) |
| | Compute byte counts of audio data into number of samples based on the audio source description used. More...
|
| |
| static size_t | toBytes (Info &info, unsigned long number) |
| | Compute the number of bytes a given number of samples in a given audio encoding will occupy. More...
|
| |
| static size_t | toBytes (Encoding encoding, unsigned long number) |
| | Compute the number of bytes a given number of samples in a given audio encoding will occupy. More...
|
| |
| static void | fill (unsigned char *address, int number, Encoding encoding) |
| | Fill an audio buffer with "empty" (silent) audio data, based on the audio encoding format. More...
|
| |
| static bool | loadPlugin (const char *path) |
| | Load a dso plugin (codec plugin), used internally... More...
|
| |
| static size_t | maxFramesize (Info &info) |
| | Maximum framesize for a given coding that may be needed to store a result. More...
|
| |
Definition at line 1926 of file audio2.h.
